3U Rack Server - 8 Hot-swap Bays - Redundant Power (Discontinued)

Model: 326S9
Model 326S9
Lead TimeDiscontinued
Price N/A
Subtotal
N/A
Configuration:
Print summary Save this Configuration Download as PDF
1
2
326S9 offers plenty of storage space in easy access hot-swap bays for storage redundancy and expansion. Additionally, two 5.25" bays to support any proprietary optical bay devices needed for the project. Anything from Blu-Ray burners or tape backup drives for production sites with physical backup needs. Ideal for projects requiring support for full-height PCI-e cards that require more inputs than available via risers in a 2U chassis. Select the KVM-Over-LAN option to provide robust remote management over existing network hardware without the need for expensive KVM cables.
Key Features:
  • Up to 8 CPU Threads
  • Up to 32GB RAM
  • Redundant Power
  • 8 x Hot-Swap Bays
Pros:
  • 8 x Hot-Swap Bays
  • Dual NICs
  • Redundant Power
  • Open 5.25" Bays
  • KVM-Over-LAN Option
Cons:
  • Loud
Recommended Uses:

Chassis
  • 3U Rack Mountable Enclosure
  • 1 Rack Unit Height (5.2")
  • Dimensions: 25.5" (D) x 19" (W) x 5.2" (H)
  • Metal thickness: 1.2 mm
Processor/Chipset
  • Socket H2 (LGA 1155)
  • Single Intel® Xeon E3-1200 series, 2nd generation Intel Core® i3, Pentium®, Celeron® processor
  • Intel® C204 PCH chipset
BIOS
  • 32Mb SPI Flash EEPROM with AMI BIOS
Memory
  • 4 x 240-pin DDR3 DIMM sockets
  • Supports up to 32 GB DDR3 ECC Un-Buffered memory (UDIMM)1333/1066/800MHz
Storage / SATA-III Ports (6Gb/s) / IPMI
  • 4 x SATA2 (3Gbps) w/ HostRAID 0, 1, 5, 10
  • 2 x SATA3 (6Gbps) w/ HostRAID 0, 1
  • Chassis supports up to eight hard drives
  • OPTIONAL: Support for IPMI 2.0 with virtual media over LAN and KVM-over-LAN, Nuvoton WPCM450 BMC
Drive Bays
  • HD1-8 Bay: Hot-swap SATA/ SSD Hard Drive
  • Up to 23 Terabyte of storage can be supported
  • Slim Optical Drive Bay
  • 2 x 5.25-inch Peripheral Bay
I/O ports
  • 2 x RJ45 port
  • 8 x USB 2.0 ports (2 x rear + 6 x via header)
  • 2 x Fast UART 16550 serial port (1 x header and 1 x rear port)
  • 1 x VGA
  • PS/2 Keyboard port
  • PS/2 Mouse port
  • OPTIONAL: 1 x RJ45 Dedicated IPMI LAN port
Video
  • Matrox G200eW 16MB DDR2 Video on-board

Network
  • Intel® 82574L, 2x Gigabit LAN ports
  • Virtual Machine Device Queues High efficient I/O overhead
  • Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
  • OPTIONAL: 1 x Realtek RTL8201N PHY (dedicated IPMI)
Hardware Monitor
  • CPU/System Fan Speed
  • CPU Temperature
  • System Voltage Vcore,+3.3V,+5V,+12V
Expansion
  • 1 x (x16) PCI-E 2.0 slot
  • 2 x (x4) PCI-E 2.0 (in x8) slots
  • 3 x PCI 32-bit slots
Power Consumption/Acoustic noise emission
  • Between W to W with the standard configuration
  • Noise level (during normal operation): ~ dBA (ISO 7779 operator position 0.6 meter).
Power Supply
  • 800W Redundant Power Supply
  • 100-240 V, 50-60 Hz, 10-4 Amp max
  • Tested to comply with FCC Standards
  • Certifications: UL, CUL, CCC, TUV, CB, EC, EN
  • High-Efficiency Redundant Power Supply (OPTIONAL)
Floppy Drive
  • Not supported
CD-ROM /DVD-ROM
  • Slim-line Optical Drive (OPTIONAL)
Rack Support
  • Rack Mounting Rails and Kit (INCLUDED)
OS Compatibility
  • Linux Ent V3 (update 6, update 7/64bit)
  • Linux Ent V3 (update 8, update 8/64bit)
  • Linux Ent V4 (update 3, update 3/64bit)
  • Linux Ent V4 (update 4, update 4/64bit)
  • Redhat Linux 9.0 (kernel 2.4.20-6 /2.4.20-8)
  • Windows XP/2003/7/2008/2008 R2
Warranty
  • 3 years Parts* and Labor Standard
  • * Batteries are subject to DOA only and are NOT subject for replacement or return
  • Extended Warranties Available
